* connect up to 18 keypads, combination LED and/or LCD * 5 programmable functions with 18 options such as Home Arm, Away Arm, Quick Exit etc. what key to press for specific functions Simple key entry to toggle between languages while viewing keypad * multi-language : English, French, Spanish The Power832 security system is fully programmable from the attractive, easy to use multi-language LCD5500 keypad: * PC5204 power supply module AC power loss * telephone line trouble - (via links cellular communicator) Trouble conditions are displayed on all keypads and can also be communicated to central station for: * programmable transmission delay by zone monitor a door by having keypad beep when the door is opened and closed security of perimeter arming while premise is occupied each partition may be programmed to auto-arm at different times

pc5010 display master code

individual open / close reporting by user

#Pc5010 display master code code

programmable system access by user code each partition can have any number of user codes which may be enabled to work on one or both partitions

pc5010 display master code

each partition acts as a separate alarm system with any number of zones, user codes, keypads and individually programmable features supervision of AC power loss, low battery, auxiliary failure positive temperature coefficient (PTC) AUX & Bell output protection separately fused battery and bell output 500 mA 12.5Vdc (400 mA for UL applications) additional high current voltage outputs using PC5204 power supply module, 1.0A 12Vdc additional low current voltage outputs using PC5208 output module, 50mA 12Vdc main panel PGM1 - low current, 50mA 12Vdc main panel PGM2 - high current switch to ground (can also be used for 2 wire smoke) additional supervised siren output using PC5204 power supply module, 1A 12Vdc, PTC protected

#Pc5010 display master code software

events can be printed on-site, viewed through the LCD Keypad or DLS software all events automatically stored with time and date stamp to buffer 1 system master code, 2 partition master codes, and duress codes 32 - 4 or 6 digit access codes assignable to one or both partitions most features programmable by partition zone options include: End of Line (EOL) resistor, Double EOL resistor, Normally Closed loops all zones programmable as burglary or fire 8 zones on main control panel (16 with zone doubler option) main panel provides up to 500mA auxiliary power PC5204 - 4 output high current power supply module provides up to 1A auxiliary power connect modules up to 1000' (330m) from control panel * supports Central Station Two Way Voice and Home Intercom features

pc5010 display master code

* supports all major formats including SIA and Contact ID 8 output transistor switch module (50 mA) 1 output fully supervised for siren output 4 output high current power supply module * PC5132-900 - wireless zone expansion module * PC5108D - 16 zone expansion module utilizing zone doubling
